Onetrak Pty ltd

Operating Weight 9,800 kg, approx.
1.2 m3 6 in 1 Front Bucket Capacity with Roll-over Forks
Extending Backhoe arm
Tyres 16.9 28 Rear, 16.9 28 Front
ENGINE & RELATED ITEMS
Perkins 11040-44TA engine, 4 Cycle, 4 Cylinder Turbocharged,
Charge Air-cooled Direct Injection, Electronic Controlled Diesel Engine.
74.5 kw (100 hp) @ 2200 rpm
410 Nm Torque @ 1300 rpm
SPECIAL ARRANGEMENTS
EPA Tier IIIA regulation arrangement.
DRIVES & BRAKES
Electronically controlled 2 or 4 Wheel Drive.
Lock up torque convertor
6 forward, 3 reverse gears.
Planetary reduction at Wheel end.
Hydraulic actuated, Wet Disc brakes actuate on all 4 Wheels.
Four-wheel steering
HYDRAULIC SYSTEM
Flow sharing and Flow charging Hydraulic System.
Variable axial piston type, 163 L/min.
Pilot pressure controlled type.
Anti-shock and anti-cavitation valves
CONTROL
Ride Control System. (MSS)
Hydrodynamic load-sensitive steering
Single lever pilot loader control.
Two joy stick backhoe control with pattern changer
Hydraulic side shift backhoe
FNR Tip Switch Kick-Down Function (forward/neutral/reverse).
Auto return to dig button (RTD)
6 in 1 Clam opening and closing proportional button
SAFETY EQUIPMENT
Factory ROPS certified cab.
Security Valves on backhoe stabilizers
Loader Arm Check Valve
Loader Bucket Check Valve
Backhoe Boom and Arm Check Valves
Anti-slip plates.
Safety glass windows.
Four front LED working lights.
Four Rear LED working lights.
Hydraulic backhoe boom lock
Dual Brake Pedals.
Emergency Brake accumulator.
OPERATOR ENVIRONMENT
Climate Controlled Air-conditioned cabin.
Adjustable steering wheel
Ergonomically designed and located control panels
CD/MP3 player.
Adjustable Suspension seat.
Adjustable backhoe control joy sticks.
Cool box
OTHER
Loader Bucket Cylinder Check Valve
Loader Arm Cylinder Check Valve
Backhoe Side Check Valve Boom and Arm
Backhoe QC Line
Stabilizer Pads
D/A piping Price Difference
Extra Hydraulic Line
Hyd. Side Shifter
Without Backhoe Bucket but with Pin Set
Front Bucket 1.2m3 Bolt on Cutting Edge
Hardened Pins 2 sets
ELECTRICAL SYSTEM
Alternator 85 Amp,
Batteries Maintenance-free 165 amp / hour
Starter motor 24V
MATERIALS
Comes with Delivery kit, Operators manual, Parts manual, Risk Assessment
WARRANTY
3 years / 6000 hours or whichever occurs first.
DELIVERY
Pricing does not include machine delivery unless otherwise quoted and shown within this submission.
Machine transport is to be calculated from the existing machine location in Australia or the nearest port / branch if not already in Australia.

HIDROMEK HMK102S SUPRA K4

HIDROMEK HMK600MG

Hyundai HL757-9 Wheel Loader
WEIGHT: 14,500KG
ENGINE:CUMMINS QSB6.7
BUCKET SIZE: 2.8M2
170hp Wheel Loader with A/C R.O.P.S. Cabin,Emergency Steering, Auto Lube, 2nd Brake, 3rd Valve, Ride Control and Reverse Camera.
Onetrak is the dealer for Hyundai Construction Equipment in Tasmania only.

HYUNDAI HL757-9

New Dressta TD25M Series-1 Crawler Dozer
Units Produced between 2021  2023 POLAND PRODUCTION
D-2 Semi-U Dozer, 9.6 cu m (12.5 cu yd), includes hydraulic tilt and manual pitch; blade includes reinforced centre push plate
Ripper with hydraulic pitch, multi-shank beam, with three shanks, includes additional ripper light, LED
Additional cab lights, 2 front, LED
Final drive rock guard
Track roller guards, full length
Transmission and engine crankcase guards, severe service
Engine, Cummins QSX15, EPA Tier 3/EU Stage IIIA

Please contact Onetrak for more information

2021 DRESSTA TD25M1 1

Anaconda ST6032 Radial Wheel Conveyor
WEIGHT: 10500KG
MISC:CONVEYORS: MAIN CONVEYOR BELT WIDTH 800MM, ADJUSTABLE DISCHARGE HEIGHT 5400MM 8250MM
POWER PACK: TIER 3 CAT C2.2 36KW OR STAGE 5 DEUTZ 2.9 L4 50KW, DIESEL TANK 92 LITRES, HYDRAULIC TANK 168 LITRES
OPERATION DIMENSION: LENGTH 23600MM, WIDTH 3600MM, ADJUSTABLE HEIGHT 7600MM 10400MM
TRANSPORT DIMENSION: LENGTH 17200MM, WIDTH 3200MM, HEIGHT 2270MM
FEEDBOOT: CAPACITY 1.3M3 3M3 WITH HOPPER EXTENSIONS
Anaconda ST6032. Anacondas range of stockpiling conveyors have been designed to maximise Stockpile volumes. Stackers are available from 20ft (6m) to 80ft (24m) with radial stockpiles of up to 5000m3. Our wheeled conveyors can be containerised in batches of 4 depending on the model.

ANACONDA ST6032

NEW Fuchs MHL350F Material Handler
Weight: 33 - 35.5 TONNE
Power: 160KW
Reach: 14.7 - 16 M

FUCHS HML350F

MODEL:ALICON HAMMER RANGE
RANGE:
ROCKBREAKERS SUIT 0.5 TON UP TO 120 TON EXCAVATORS.
ADVANCED FUNCTIONS:
ABF (ANTI BLANK FIRING) SYSTEM, TPC (TOTAL POWER CONTROL) SYSTEM, INTERNAL RELIEF VALVE, BPM ADJUST VALVE, PROVISION HOLE FOR UNDER WATER WORKS AND AUTO GREASE SYSTEM.
Alicon Breakers are produced by the leading South Korean attachment manufacturer Daemo. The companys business started over 30 years ago with the production of hydraulic breakers. The Alicon breakers features superior crushing force and durability.

DAEMO ALICON

NEW Anaconda FTR150 Feeder Conveyor

The FTR150 is robust and can be used in a variety of applications including sand & gravel, aggregates, compost and coal. The unit has a variable speed belt feeder and a 50ft stockpiling conveyor which is ideal for truck/wagon/barge loading or to act as a surge feeder in a new or existing quarry plant.

Weight: 13300kg - Weight with Tipping Grid 15000kg - Weight with Vibrating Grid 17800kg
Power Pack: TIER 3 JCB 444 DIESELMAX  63KW Engine, Diesel Tank 160 Litre, Hydraulic Tank 345 Litre
Operation Dimension: Length 17300mm, Width 2250mm, Height 6580mm
Transport Dimension: Length 11900mm, Width 2250mm, Height 2500mm
Feeder: Capacity 10m3 with extensions, Belt Feeder, Feeder Conveyor Belt Width 1050mm

ANACONDA FTR150

New Tigercat 760B Mulcher with 4061-30 Mulching Head

ENGINE Tigercat (FPT) C13 420 kw (563hp) @ 1,800 rpm tier 2 engine

WHEELS 35.5 x 32, 30PR Firestone CRC

BRAKES Spring applied, hydraulic release, wet friction disc type

CONTROLS Electronic for travel/steering/boom, joystick control. Electronic travel speed control limiter, cruise control. Electronic control system with colour LCD touchscreen for machine monitoring and function adjustment

COOLING SYSTEM Side-by-side aluminium radiator, oil cooler, charge air cooler and A/C condenser; Aluminium pump drive gearbox cooler; Swing-out intake debris screen

HYDRAULICS Dedicated variable displacement pumps for attachment and boom

CAB Insulated, pressurized and isolation mounted, two doors with 12mm (1/2") thick polycarbonate windows (in lieu of glass) with guards; Removable steel and polycarbonate skylight, Air-conditioned, heater and defroster, forward sloping polycarbonate windshield

RADIO AM/FM digital stereo with CD player; Bluetooth® audio and hands-free calling

LIGHTING High output LED work lights

ACCESSORIES Compressed air package includes engine driven air compressor, hydraulic tank vacuum system

BOOM FLOAT FUNCTION Standard boom float functionality built in

ATTACHMENT Tigercat 4061-30 Mulching head 3.0m (10ft) w/ hydraulic push bar, debris door, poly-chain belt drive and variable displacement motors. Oscillating frame to carrier connection, taper tooth rotor with 60 triple carbide teeth, straight shear bar, steel chain style debris guard kit, rubber debris guard kit, wear liner insert.

FIRE SYSTEM Fogmaker fire suppression system (factory installed), requires activation and certification by distributor or owner prior to placing machine in service

FUEL FILL SYSTEM Ground level fuelling system

WINCH 35,000 lbs hydraulic recovery winch (cable not included)

TELEMATICS LogOn local wifi machine monitoring system.

OTHER
Electric hydraulic oil fill pump
Rear camera systems
Boom float system
Air compressor with 24,5 L (6.5 US gal) tank
Booster cable 6m - connector plug - clamps
Pre-cleaner guard extension

ONETRAK PRODUCT SUPPORT PLUS Hydraulic tune & inspection every 1000 hours up to & inc 4000hrs. UHF Radio supplied & fitted (manufactures warranty only)

MANUALS 2 operation and 1 parts manuals.

COMMISSIONING Includes 1 full day commissioning by experienced Onetrak representative.

RISK ASSESSMENT Supplier risk assessment upon pre-delivery.

WARRANTY Standard warranty - 1 year/ 2000 hrs whichever occurs first. Secure drivetrain + engine - 3 years/ 6000 hrs whichever occurs first

DELIVERY Pricing does not include machine delivery unless otherwise quoted and shown within this submission. Machine transport is to be calculated from the existing machine location in Australia or the nearest port / branch if not already in Australia.

PRICING Prices are subject to change without notice, this quotation is valid for fourteen (14) days. Orders are subject to confirmation and factors such as factory price movements, shipping and currency fluctuations.

TIGERCAT 760B

Anaconda DF518 Scalper
WEIGHT: 35000KG
POWER PACK:TIER 3 - CAT C4.4 75KW, DIESEL TANK 390 LITRE, HYDRAULIC TANK 450 LITRE
OPERATION DIMENSION: LENGTH 15490MM, WIDTH 13840MM, HEIGHT 4860MM
TRANSPORT DIMENSION: LENGTH 15800MM, WIDTH 3000MM, HEIGHT 3400MM
FEEDER: CAPACITY 8M3, BELT FEEDER OR APRON FEEDER, FEEDER CONVEYOR BELT WIDTH 1200MM
SCREENBOX: TOP DECK 5490MM X 1520MM (18 X 5) BOTTOM DECK 5490MM X 1520MM (18 X 5), ANGLE 13-17 DEGREES
The Anaconda DF518 Tracked Scalping Screen is versatile and economical to run and can screen / stockpile 3 products at up to 400TPH. The DF518 has a double deck 18 X 5 screen box, a Hopper Capacity of 8M3 and 3 hydraulically folding stockpiling conveyors. The screen is very easy to set up and can be running within 20 minutes with hydraulic controls to aid the setting up of all conveyors, screen-box and hopper wing plates.

ANACONDA DF518

HIDROMEK 460MG

NEW Trommel Screen, Tier 3 JCB 444 DieselMAX - 85kw Engine, Capacity up to 200 T/Hour

ANACONDA TD620
